【电工钢硅钢片汽车车轮用钢用心制作】

电工钢硅钢片B27G120表示公称厚度为0.27mm普通取向电工钢，铁损的保证值P17/50不大于1.20W/kg；B30P105表示公称厚度为0.30mm高磁感取向电工钢，铁损的保证值P17/50不大于1.05W/kg；B27R090表示公称厚度为0.27mm磁畴细化高磁感取向电工钢，铁损的保证值P17/50不大于0.90W/kg；电工钢主要分为晶粒取向电工钢和晶粒无取向电工钢两大类。取向电工钢易磁化晶粒方向沿轧制方向分布，轧制方向具有高磁感、河北承德同城低铁损及低磁致伸缩等优良特性，同时还可通过磁畴细化的技术处理，获得更低铁损的性能，广泛应用于变压器行业领域。

电工钢硅钢片Electrical steel, also known as silicon steel sheet, is an indispensable metal material in the power, electronics, and military industries, and is also the largest functional material in production. It is mainly used as the iron core for various motors, generators, and transformers. Specific total loss (iron loss) is the total power consumed per unit mass of material when the magnetic polarization waveform remains sinusoidal, with a specific peak and frequency. The specific total loss is represented by the symbol P (Jm/f), in W/kg. Example: P1.5/50 represents the specific total loss at a maximum magnetic polarization intensity of 1.5T and a frequency of 50Hz. 3.2 Magnetic Polarization Q/BQB 480-20212 Magnetic polarization intensity refers to the peak magnetic polarization intensity of a specific magnetic field intensity when a sample is subjected to alternating magnetization. Its symbol is J (H), and the unit is T (Tesla). Example: J5000 represents the peak magnetic polarization intensity corresponding to a magnetic field intensity peak of 5000A/m. The material grades in this document are classified based on the nominal maximum specific total loss P1.5/50 (W/kg) at a magnetic polarization strength of 1.5T and a frequency of 50Hz, as well as the nominal thickness of the material. They are further divided into three categories based on product characteristics: ordinary type, stress relief annealing type, and high-efficiency type. Example 1: B35A210 represents a common non oriented electrical steel with a nominal thickness of 0.35mm, and the maximum nominal specific total loss value P1.5/50 is 2.10W/kg； Example 2: B35AR300 represents a stress relieved annealed non oriented electrical steel with a nominal thickness of 0.35mm, and the maximum nominal specific total loss value P1.5/50 is 3.00W/kg； Example 3: B35AH230 represents an efficient non oriented electrical steel with a nominal thickness of 0.35mm, and the maximum nominal specific loss value P1.5/50 is 2.30W/kg. Example 4: 35WW210 represents a normal type WW non oriented electrical steel with a nominal thickness of 0.35mm, and the maximum nominal specific loss value P1.5/50 is 2.10W/kg. Example 5: 35WH230 represents an efficient WH non oriented electrical steel with a nominal thickness of 0.35mm, and the maximum nominal specific loss value P1.5/50 is 2.30W/kg. The classification and code of insulation coatings shall comply with the provisions of Table 2. Table 2 Classification and Code of Insulation Coatings Type Code Characteristics of Insulation Coatings Semi organic Thin Coating A Improves Punching Performance and Has Good Weldability Semi organic Thick Coating H has Good Punching Performance and High Interlayer Resistance Semi organic Chromium Free Thin Coating K does not contain chromium and has good weldability Semi organic Chromium Free Thick Coating M does not contain chromium and has good insulation performance Semi organic Chromium Free Extreme Thick Coating J does not contain chromium and has excellent insulation performance Semi organic Chromium Free Ultra Thick Coating L does not contain chromium and has extremely high insulation performance Self adhesive Coating

电工钢硅钢片表 4 普通型 WW、河北承德型 WH 产品磁性能和技术特性类型 牌号公称厚度mm 比总损耗名义值P1.5/50 W/kg 比总损耗P1.5/50 W/kg小磁极化强度J5000a T比总损耗各向异性T1.5/50b ％小叠装系数小弯曲次数约定密度kg/dm3普通型35WW2300.352.30 2.10 1.62 ±170.952 7.6035WW250 2.50 2.28 1.64 ±17 2 7.6035WW270 2.70 2.45 1.64 ±17 2 7.6035WW300 3.00 2.65 1.64 ±17 2 7.6535WW360 3.60 3.20 1.65 ±17 3 7.6535WW440 4.40 3.40 1.67 ±17 3 7.7050WW2500.502.50 2.30 1.64 ±170.972 7.6050WW270 2.70 2.48 1.64 ±17 2 7.6050WW290 2.90 2.65 1.64 ±17 2 7.6050WW310 3.10 2.85 1.64 ±17 2 7.6050WW350 3.50 3.00 1.65 ±14 3 7.6550WW400 4.00 3.20 1.65 ±12 5 7.6550WW470 4.70 3.30 1.70 ±12 5 7.7050WW600 6.00 4.20 1.68 ±10 10 7.7550WW700 7.00 4.70 1.70 ±10 10 7.8050WW800 8.00 5.50 1.71 ±10 10 7.8050WW1000 10.00 6.00 1.74 ±8 10 7.8550WW1300 13.00 7.00 1.74 ±8 10 7.85型35WH2300.352.30 2.28 1.66 ±170.952 7.6535WH250 2.50 2.45 1.67 ±17 2 7.6535WH270 2.70 2.65 1.68 ±14 5 7.7035WH300 3.00 2.80 1.69 ±14 5 7.70
